800 SLAM Rack 12U


Unbeatable impact protection against the rigors of the road!

Fiasco SLAM Racks provide unparalleled protection against the harsh conditions of the road. Each one is precision cut and crafted by our team in Cambridge, New Zealand, using top-of-the-line Penn Elcom hardware.

The 19" sub-frame is suspended in a Penn R8800 anti-vibration shock mount, cushioning your gear against even the most significant jolts. The result is a SLAM Rack that increases the lifespan of your valuable touring equipment.

The slam doors are securely mounted on hinged, sliding rails and can be neatly stowed away beside the rack ears when not in use, eliminating the need for additional storage space for lids.

Ball corners add further strength and structure to your SLAM Rack by shielding it against any direct punches it may encounter on the road. The overall rigid structure of the SLAM Rack also means it won’t trapezoid over time.

Each SLAM Rack features plenty of breathing space on the rack's sides - top, bottom, front, and back - helping to increase airflow around your gear to reduce the risk of it overheating.

Sufficient space between the slam doors and the rack itself means that you have the ability to keep cables patched, even when the doors are closed.

12U SLAM Racks are great for transporting your power distros, audio i/o,  DMX distros, or media servers.

Stacking cups allow you to stack and pack your Fiasco SLAM Racks with any other Fiasco Rack or Road Case, no matter the size or footprint.



A perfect fit in any transport, 800 Cases are optimised for 2.4m Truck Packology:

  • Pack 4 side-by-side in 2400mm box trucks and semi-trailers
  • Pack 3 end-to-end in 2400mm box trucks and semi-trailers

PRODUCT SPEC SHEET COMING SOON!

Contact us for a quote
Shock Rack System Penn Elcom anti-vibration
Shock Mount Rating 90kg
Rack Spaces 12U
Rack Depth 607mm front to rear ear
Rack Ears Fitted with front and rear rack ears
Mounting fixtures M6 screws, washers & cage-nuts incl.
Sidings Black resin impregnated 9mm Birch Ply
Wheel-board 18mm Birch Ply with low lifting cut-outs
Extrusions 2mm proprietary 6061-T6 alloy
Hardware Penn Elcom zinc plated fittings
Wheels Penn Elcom 250kg 4" blue castors
Label Label dish with shower proof gaskets
Case Dimensions
(D x W)
590 x 790mm



We ship throughout New Zealand via Toll, Mainfreight and Post Haste Courier service.

If your order is small, like a Polyproof Case, we will typically send this via 1-3 day courier on the next business day.

If your order is larger, it will come via Toll or Mainfreight's trucking network within 1-7 days.
