LX Profile Case
Designed especially for the latest generation of profile lights. The LX Profile Case boasts several innovative features. Rather than dividing a standard trunk up into ellipsoidal-sized compartments, our design team reimagined the design from scratch. The result is a cutting-edge lighting road case that we believe is more space-efficient, more versatile, and more ergonomic than other existing options.
Not only is the LX Profile Case designed to take the newer wave of profile lights, it can accommodate most lens configurations too, unlike standard trunks. The case can take lights fitted with any of the standard 14º to 90º lens options for fixed focus; and 15º–30º and 25–50º zooms options also.
The case works with the LED ETC Source Four, the Chauvet Ovation LED Ellipsoidal range, and EK Profile lights. In addition to these and other recent profile lights, the case is compatible with the traditional Source Four. That versatility means the case will be a total solution for most production companies.
Our foldable, semi-detachable sides mean the lift-over height of the case is significantly lower than standard cases. This allows for easy, ergonomic access to profile lights. Since the dimensions are compatible with other Fiasco cases, both models of case fit within the larger “Truck Packology” system.
|Sidings||Black hex resin impregnated 9mm Birch Ply|
|Wheel-board||15mm Birch Ply with low lifting cut-outs|
|Extrusions||2mm proprietary 6061-T6 alloy|
|Hardware||Penn Elcom zinc plated fittings|
|Wheels||Penn Elcom 250kg 4" blue auto castors|
|Wheel pockets||Shower proof gaskets|
|Label||Label dish with shower proof gaskets|
Ball to Ball sizes
(D x W x H)
|590 x 790 x 1243mm|
